Main features
● Rinsing sector and water flow system adopt rustproof and rot-proof material, which can bear roughly usage.
● The rinsing and dry sector with floating design is suitable for rinsing 3-12mm glasses.
● Full distance automatic changeable frequency speed adjustment, which can save work waiting time and improve production efficiency.
● The glasses can be rinsed continuously, the machine can distinguish the first and the second glass automatically. waiting time is zero.
● Adopt the imported low-voltage electric apparatus component, sensor, the equipment is automatically controlled by PLC for the whole operation.
● This machine is in high efficiency; it has storage room for little piece of glass. Washing the glass can be imported in succession.
● The machine can produce extend, big & small, unique shape insulating glass.
- Place of Origin: china
- Brand Name: huashinuo
- Model Number: 60005
Main technical parameter
Type | LB1800P | Type | Lb1600p |
Power supply | 380V50Hz (Customized) | Power supply | 380V 50Hz (Customized) |
Min glass size | 450mm×450mm | Min glass size | 450mm×500mm |
Max glass size | 1800mm×2500mm | Max glass size | 1600mm×2000mm |
Pane glass thickness | 3-12mm | Pane glass thickness | 3-12mm |
Max.I.G.Unit thickness | 12-40mm | Max.I.G.Unit thickness | 12-40mm |
Glass cleaning speed | 0-8m/min | Glass cleaning speed | 0-8m/min |
Working speed | 2-22m/min | Working speed | 2-22m/min |
Air pressure | 1M pa | Air pressure | 1M pa |
Input power | 21.95kw | Input power | 18kw |
Size(l× w × h) | 15000×1800×2630mm | Size(I× w × h) | 13500×1600×2630mm |
