Product Details
- Place of Origin: china
- Brand Name: huashinuo
- Model Number: 60003
Main features
● Used for cutting aluminum and PVC at -45° 90°45°.
● The right head can be adjusted horizontally by the motor.
● Two heads work independently or together.
● Uniform speed feeding and smooth motion due to airdraulic damping cylinder
- Place of Origin: china
- Brand Name: huashinuo
- Model Number: 60003
Main technical parameter
Power supply | 380V 50Hz (Customized) |
Main motor power | 2 × 1.5 0.55Kw |
Air pressure | 0.4-0.6 M pa |
Air consumption | 60L /min |
Main motor rotation speed | 2800r/min |
Min/max Cutting length | 360-3700mm |
Saw blade dimension | Φ450× φ30 Z=120 |
Cutting angle | -45 ° 90 ° 45 ° |
Cutting W x H | 120× 150mm |
Size(length× width × height) | 4500mm × 1250mm × 1550mm |
Weight | 790Kg |
