Product Details
- Place of Origin: china
- Brand Name: huashinuo
- Model Number: 60002
Main Specification:
1. Used for milling production of all kinds of holes and slot in aluminum window and door.
2. Guiding device for machine head vertical moving enhanced the milling distance and accurate position
3. Linear bearing used in the level moving ensured the accurate position for hole/slot shape milling.
4. High steel body with enhance design to ensure the stable working.
- Place of Origin: china
- Brand Name: huashinuo
- Model Number: 60002
Technical Parameter:
| Power supply | 380V 50Hz or according to order |
| Operation air pressure | 0.5~0.8Mpa |
| Motor power | 0.75KW |
| Air consumption | 20L/min |
| Milling cutter rotary speed | 12000r/min |
| Milling cutter specification | φ5×60,φ8×80 |
| Processing dimension range | H-100mm W-120mm |
| Drill template specification | 100mm×290mm |
| Dimension | 870×700×1500mm(L*W*H) |
| Weight | 210kg |
