- Place of Origin: China
- Brand Name: huashinuo
- Model Number: LJVW-60
Main Specification
1. Automatic V-cutting of UPVC window profile.
2. Pneumatic clamping.
3. Adjustable V-notch depth based on different profile.
4. Adjustable feeding speed.
5 .Reasonable structure, safe and convenient operation.
6. Two saw blade on two separate motor fixed at 45 degree without cross.
Technical Parameter
| Air Pressure | 0.5~0.8(MPa) |
| Air Consumption | 80(L/min) |
| Input Voltage | 380V 50HZ or according to order |
| Input Power | 1.5(Kw) |
| Spindle Rotary Speed | 2800(r/min) |
| Saw Blade Specification | ø300x3.2x ø30 |
| Cutting Height | 20-60(mm) |
| Cutting Width | 120(mm) |
| Cutting Length | 300-1600(mm) |
| Overall Dimension | 1300*700*1350mm |
| Weight | 220(kg) |
