- Place of Origin: China
- Brand Name: huashinuo
- Model Number: SJZ2-400*3500
Main Specification
1. Used for not only aluminum profile and curtain wall profile cutting, but also upvc profile cutting.
2. Feeding system adopts imported circular linear guide rail with high accurate and long service life.
(Right head moves by manual pull-push ,but it is good for circular guide rail )
3. 45°and 90° cutting is available.（Adjusting angle by manual tools or button automatically ）
4. Imported carbide saw blade gives accurate processing and high endurance
5. Uniform speed feeding and smooth motion due to air hydraulic damping cylinder
6.Auto-opening guard cover ensures safe operation.
Technical Parameter
| Power supply | 380V 50Hz (Customized) |
| Main motor power | 2 × 1.5Kw |
| Air pressure | 0.5-0.8 M pa |
| Air consumption | 60L /min |
| Main motor rotation speed | 2800r/min |
| Min/max Cutting length | 480-3700mm |
| Saw blade dimension | Φ450× φ30 Z=120 |
| Cutting angle | -45 ° 90 ° 45 ° |
| Cutting W x H | 120× 160mm |
| Size(length× width × height) | 4500mm × 1170mm × 1400mm |
| Weight | 790Kg |
